Model Number

QLG9380TJZG

Rated Load

45000 kg

Tare Weight

6500 kg

Wheel Base

4300+1310 (mm)

Tyre Specifications

1100R20-18/12R22.5-18

No. Of the Tyres

8

Axle Brand

FUWA (BPW optional)

No. Of the Axles

2

Axle-load

24000 kg

King Pin

50#/90#

Landing Leg

28ton

Pieces of leaf-spring

9/10

Suspension

independent stamping steel rigid suspension (or air suspension)

Departure Angle

14.5

Front/Rear Overhang

2120 mm

Outside Dimensions (LxWxH)

6500X2450X1550 (mm)

Material of the Main Beam

Q345B manganese plates, automatic submerged arc welded

Brake System

Dual line braking system /ABS

Brake Air Chamber

four double chamber

Electrical

24V  7 ways(7 wire harness)

Color

Any color will be available

Accessory

One tooling box with a set of standard trailer tool

Twist lock

12 PCS
