Product Specifications | |
Model Number | QLG9402TDP |
Rated Load | 60000 kg-80000kg |
Tare Weight | 13000 kg |
Wheel Base | 12030+1220+1220, 11530+1220+1220 (mm) |
Tyre Specifications | 8.25R20-16PR,1100R20-18PR |
No. Of the Tyres | 24 |
Axle Brand | FUWA (BPW optional) |
No. Of the Axles | 3 lines with 6 axles |
Axle-load | 24000 kg |
King Pin | 50#/90# |
Landing Leg | 28ton |
Suspension | rigid suspension |
Departure Angle | 20 |
Front/Rear Overhang | 1100 mm |
Outside Dimensions (LxWxH) | 16000,15500X3000, 2800X3150,1710 (mm) |
Material of the Main Beam | Q345B manganese plates, automatic submerged arc welded |
Brake System | Dual line braking system /ABS |
Electrical | 24V 7 ways(7 wire harness) |
Usage | Is applicable for the transportations of the mechanical equipment, large objects, highway construction equipment, large tanks, power plant equipment or machine, and all sorts of steel products. |
Other Specifications | The cargo's carrying platform is 910mm high from the ground, and the overall height is 1710mm without the ladders. |
Other Descriptions | The whole body adopts steel with good quality, and be manufactured by advanced skills and strict producing managerial processes. The frame is wearing structure, webs made from manganese plates from 400mm to 550mm high welded the upper and lower flangeplates together, and the beam runs through the longitudinal beam makes the two parts a very strong unit by automatic submerged arc welding. Frame using peen-forming processing. |
