Brand | Qi Lin |
Model | QLG9401GFL |
Usage | |
Total weight | 40000kg |
Tare weight | 11500kg |
Max payload | 28500kg |
Tank volume | 49cbm |
Overall dimension | 13000mm*2500mm*3950mm |
Tank dimension | 11910mm*2470mm*3210mm |
Side protective device | Q235 steel,screw bolt connection |
Rear protective device | Q235 steel,welding connection |
Bottom edge height | 550mm |
Axle | 24000kg payload/3pcs |
Tire | 11.00R20 12PR,12R22.5 12PR/12pcs |
Leaf spring number | -/9/9/9 |
Wheelbase | 7930mm+1310mm+1310mm |
Rear tread | 1840mm/1840mm/1840mm |
Rear suspension | 1000mm |
Departure angle | 33° |
Braking system | With ABS system(CM2XL-4S/2K(4S/2M)) |
Electrical system | 24 voltage,7 wire harness. |
Light | LED type |
Painting | With shot blasting and 4 layers painting,color is optional. |
Remark | The above mentioned data is for your reference only. The detailed specification will be subject to our final confirmation. |
