Model

QLG5060GJY-DH

Usage

For fuel transportation and charging

Total weight

7350kg

Tare weight

3655kg

Max payload

3500kg

Tank volume

5.25cbm

Overall dimension

5995mm*1995mm*2450mm

Tank dimension

4080mm*1660mm*1160mm

Protective device

Q235 steel,screw bolt connection

Bottom edge height

550mm

Axle load

2350kg/5000kg

Axle number

2pcs

Tire

7.00R16 14PR/6pcs

Leaf spring number

6/6+5,8/9+5

Front/rear tread

1586mm/1530mm

Front/rear suspension

1115mm/1580mm

Wheelbase

3300mm

Approach/departure angle

27°/22°

Braking system

With ABS system(36BG13-30010)

Max speed

80km/h

Passenger limit

3 persons

Fuel type

Diesel

Electrical system

24 voltage,7 wire harness.

Light

LED type

Painting

With shot blasting and 4 layers painting,color is optional.

Remark

The above mentioned data is for your reference only.

The detailed specification will be subject to our final confirmation.
