Brand | Qi Lin |
Model | QLG5070GJY1 |
Usage | For fuel transportation and charging |
Total weight | 7360kg |
Tare weight | 3560kg |
Max payload | 3605kg |
Tank volume | 4.5cbm |
Overall dimension | |
Tank dimension | 4000mm*1600mm*1000mm |
Protective device | Q235-A steel,screw bolt connection |
Bottom edge height | 490mm |
Axle load | 2945kg/4415kg |
Axle number | 2pcs |
Tire | 7.00R16/6pcs |
Leaf spring number | 6/6+5 |
Front/rear tread | 1503mm/1494mm |
Front/rear suspension | 1040mm/1647mm |
Wheelbase | 3308mm |
Approach/departure angle | 20°/14° |
Braking system | With ABS system(ABS/ASR-24V-4S/4M) |
Max speed | 80km/h |
Passenger limit | 2 persons |
Fuel type | Diesel |
Electrical system | 24 voltage,7 wire harness. |
Light | LED type |
Painting | |
Remark | The above mentioned data is for your reference only. The detailed specification will be subject to our final confirmation. |
