Model

QLG5070GJY

Usage

For fuel transportation and charging

Total weight

7360kg

Tare weight

3560kg

Max payload

3670kg

Tank volume

5.5cbm

Overall dimension

5995mm*1990mm*2430mm

Tank dimension

3980mm*1730mm*1190mm

Bottom edge height

470mm

Axle load

2360kg/5000kg

Axle number

2pcs

Tire

7.00R16/6pcs

Front/rear tread

1620mm/1395mm

Front/rear suspension

1105mm/1582mm

Wheelbase

3308mm

Approach/departure angle

23°/22°

Braking system

With WABCO ABS system(ABS-E 4S/4M)

Max speed

80km/h

Passenger limit

2 persons

Fuel type

Diesel

Electrical system

24 voltage,7 wire harness.

Light

LED type

Painting

With shot blasting and 4 layers painting,color is optional.

Remark

The above mentioned data is for your reference only.

The detailed specification will be subject to our final confirmation.
