Brand | Qi Lin |
Model | QLG5080GJY |
Usage | For fuel transportation and charging |
Total weight | 8280kg |
Tare weight | 3900kg |
Max payload | 4185kg |
Tank volume | 5.1cbm |
Overall dimension | 5995mm*2050mm*2600mm |
Tank dimension | 4000mm*1640mm*1120mm |
Protective device | Q235-A steel,screw bolt connection |
Bottom edge height | 490mm |
Axle load | 3090kg/5190kg |
Axle number | 2pcs |
Tire | 7.50R16/6pcs |
Leaf spring number | 3+1/6+7 |
Front/rear tread | 1710mm/1590mm |
Front/rear suspension | 1120mm/1515mm |
Wheelbase | 3360mm |
Approach/departure angle | 22°/21° |
Braking system | With WABCO ABS system |
Max speed | 80km/h |
Passenger limit | 3 persons |
Fuel type | Diesel |
Electrical system | 24 voltage,7 wire harness. |
Light | LED type |
Painting | |
Remark | The above mentioned data is for your reference only. The detailed specification will be subject to our final confirmation. |
