Brand | Qi Lin |
Model | QLG5081GJY |
Usage | For fuel transportation and charging |
Total weight | 8280kg |
Tare weight | 3850kg |
Max payload | 4235kg |
Tank volume | 5.3cbm |
Overall dimension | 5995mm*2100mm*2650mm |
Tank dimension | 3900mm*1640mm*1100mm |
Protective device | Q235-A steel,screw bolt connection |
Bottom edge height | 490mm |
Axle load | 3050kg/5230kg |
Axle number | 2pcs |
Tire | 7.50R16 14PR,8.25R16 14PR/6pcs |
Leaf spring number | 3/3+4,7/10+3 |
Front/rear tread | 1640mm/1590mm |
Front/rear suspension | 1150mm/1585mm |
Wheelbase | 3260mm/3300mm |
Approach/departure angle | 21°/17° |
Braking system | With ABS system (VIE ABS-II) |
Max speed | 80km/h |
Passenger limit | 3 persons |
Fuel type | Diesel |
Electrical system | 24 voltage,7 wire harness. |
Light | LED type |
Painting | |
Remark | The above mentioned data is for your reference only. The detailed specification will be subject to our final confirmation. |
