Model

QLG9400GRH

Usage

Load lubricating oil

Total weight

40000kg

Tare weight

9480kg

Max payload

30520kg

Tank volume

36cbm

Overall dimension

11300mm*2500mm*3900mm

Tank dimension

10930mm*2490mm*2000mm

Side/Rear protection connect type

Screw bolt / Welding

Bottom edge height

520mm

Axle

24000kg load/3pcs

Tire

11.00R20 12PR/12pcs

Wheelbase

5670mm+1310mm+1310mm

Rear tread

1840mm/1840mm/1840mm

Rear suspension

1300mm

Departure angle

22°

Braking system

With ABS system(CM2XL-4S/2M)

Electrical system

24 voltage,7 wire harness.

Light

LED type

Painting

With shot blasting and 4 layers painting,color is optional.

Remark

The above mentioned data is for your reference only.

The detailed specification will be subject to our final confirmation.
