Model

QLG9404GSY

Usage

Load edible oil

Total weight

40000kg

Tare weight

9460kg

Max payload

30540kg

Tank volume

40cbm

Overall dimension

13000mm*2490mm*3900mm

Tank dimension

8550mm*2490mm*1630mm

Side protective device

Q235 steel,screw bolt connection

Rear protective device

Q235 steel,welding connection

Bottom edge height

500mm

Axle load

24000kg

Axle number

3pcs

Tire

11.00R20 12PR/12pcs

Leaf spring number

-/13/13/13

Wheelbase

7000mm+1305mm+1305mm

Rear tread

1840mm/1840mm/1840mm

Rear suspension

1650mm

Departure angle

22°

Braking system

With ABS system(4S/2M)

Electrical system

24 voltage,7 wire harness.

Light

LED type

Painting

With shot blasting and 4 layers painting,color is optional.

Remark

The above mentioned data is for your reference only.

The detailed specification will be subject to our final confirmation.
