Model

QLG9401GRYB

Usage

Load diethyl ether

Total weight

40000kg

Tare weight

10000kg

Max payload

30000kg

Tank volume

42cbm

Overall dimension

11500mm*2500mm*3900mm

Tank dimension

11000mm*2290mm*2040mm

Tank insulating layer

100mm thickness

Side protective device

Q235 steel, screw bolt connection

Rear protective device

Q235 steel, welding connection

Bottom edge height

530mm

Axle load

24000kg

Axle number

3pcs

Tire

11.00R20 12PR,12R22.5 12PR/12pcs

Leaf spring number

-/9/9/9,-/13/13/13

Wheelbase

5840mm+1305mm+1305mm

Rear tread

1840mm/1840mm/1840mm

Rear suspension

1500mm

Departure angle

20°

Braking system

With ABS system (CM2XL-4S/2K(4S/2M))

Electrical system

24 voltage,7 wire harness.

Light

LED type

Painting

With shot blasting and 4 layers painting,color is optional.

Remark

The above mentioned data is for your reference only.

The detailed specification will be subject to our final confirmation.
