Brand | Qi Lin |
Model | QLG9403GRYA |
Usage | Load flammable liquids |
Total weight | 40000kg |
Tare weight | 10000kg |
Max payload | 30000kg |
Tank volume | 33cbm |
Overall dimension | 11350mm*2500mm*3900mm |
Tank dimension | 10850mm*2490mm*2000mm |
Tank insulation | 100mm thickness insulating layer |
Side protection connect type | Screw bolt |
Rear protection connect type | Welding |
Bottom edge height | 550mm |
Axle | 24000kg payload/3pcs |
Tire | 12R22.5 12PR/12pcs |
Wheelbase | 5750mm+1310mm+1310mm |
Rear tread | 1840mm/1840mm/1840mm |
Rear suspension | 1400mm |
Departure angle | 22° |
Braking system | With ABS system(HNABS4S/4M) |
Electrical system | 24 voltage,7 wire harness. |
Light | LED type |
Painting | |
Remark | The above mentioned data is for your reference only. The detailed specification will be subject to our final confirmation. |
