Model

QLG9409GRY

Usage

Load benzene,crude oil,coal tar,fuel oil etc.

Total weight

40000kg

Tare weight

10300kg

Max payload

29700kg

Tank volume

35cbm

Overall dimension

12000mm*2500mm*3900mm

Tank dimension

11400mm*2490mm*2150mm

Tank shape

Gooseneck type

Tank insulating layer

100mm thickness

Side protective device

Q235 steel,screw bolt connection

Rear protective device

Q235 steel,welding connection

Bottom edge height

520mm

Axle

24000kg payload/3pcs

Tire

11.00R20 12PR,12R22.5 12PR/12pcs

Leaf spring number

-/10/10/10,-/9/9/9,-/13/13/13

Wheelbase

6180mm+1310mm+1310mm

Rear tread

1840mm/1840mm/1840mm

Rear suspension

1650mm

Departure angle

22°

Braking system

With ABS system(CM2XL-4S/2M)

Electrical system

24 voltage,7 wire harness.

Light

LED type

Painting

With shot blasting and 4 layers painting,color is optional.

Remark

The above mentioned data is for your reference only.

The detailed specification will be subject to our final confirmation.
