Brand | Qi Lin |
Model | QLG5110GYY |
Usage | |
Total weight | 11495kg |
Tare weight | 4890kg |
Max payload | 6410kg |
Tank volume | 8.1cbm |
Overall dimension | 7000mm*2150mm*2650mm |
Tank dimension | 4760mm*1900mm*1270mm |
Protective device | Q235-A steel,screw bolt connection |
Bottom edge height | 470mm |
Axle | 4595kg/6900kg payload/2pcs |
Tire | 8.25R20 14PR/6pcs |
Leaf spring number | 8/10+7,11/9+7 |
Front/rear tread | 1770mm/1640mm |
Front/rear suspension | 1210mm/1990mm |
Wheelbase | 3800mm |
Approach/departure angle | 24°/14° |
Fuel type | Diesel |
Passenger number | 3 persons |
Max speed | 80km/h |
Braking system | With ABS system(36BG13-30010) |
Electrical system | 24 voltage,7 wire harness. |
Light | LED type |
Painting | With shot blasting and 4 layers painting,color is optional. |
Remark | The above mentioned data is for your reference only. The detailed specification will be subject to our final confirmation. |
