Brand | Qi Lin |
Model | QLG5120GYY |
Usage | Load diesel/gasoline |
Total weight | 11990kg |
Tare weight | 5300kg |
Max payload | 6495kg |
Tank volume | 8.1cbm |
Overall dimension | 6950mm*2200mm*2800mm |
Tank dimension | 4800mm*1920mm*1280mm |
Protective device | Q235-A steel,screw bolt connection |
Bottom edge height | 470mm |
Axle | 4200kg/7790kg payload/2pcs |
Tire | 8.25R20 16PR/6pcs |
Leaf spring number | 9/11+7 |
Front/rear tread | 1685mm/1615mm |
Front/rear suspension | 1120mm/2030mm |
Wheelbase | 3800mm |
Approach/departure angle | 24°/14° |
Fuel type | Diesel |
Passenger number | 3 persons |
Max speed | 80km/h |
Braking system | With WABCO ABS system |
Electrical system | 24 voltage,7 wire harness. |
Light | LED type |
Painting | With shot blasting and 4 layers painting,color is optional. |
Remark | The above mentioned data is for your reference only. The detailed specification will be subject to our final confirmation. |
