Overall dimension

5000mm*2500mm*1320mm

Fifth wheel load

10 tons

Curb Weight

3 tons

Main beam

Q345b/ST52.3steel,500mm height.

upper/down wing plate 18mm,middle plate 10mm.

Cross beam

100*63*6mm I beam steel

Fifth wheel

90#/3.5’

Axle

13T FUWA*2pcs

Tire

Triangle 385/65R22.5*4pcs

Leaf spring

90mm*13mm*10pcs*4sets

Suspension

Mechanical suspension

Drawbar

1 standard follow customer’s drawing

Electrical system

24 volt electrical system,7pin electrical connector.

Parking stop,reverse,number plate and indicator lights,rear lights

conform to European standard.Rear front and side reflectors.
