Tare weight | About 6.5 tons |
Dimension | 12500mm*2500mm*1600mm (three or two axles)40FT |
Loading capacity | 60T(40FT) |
Axle | 13 T/16T, FUWA /BPW /Huajing Brand |
Rim | 9.00-22.5 |
Tire | 12.00R22.5 315/80R22.5 |
Suspension | Mechanical suspension (Germany Type or America Type) |
Leaf spring | 90(W)mm*13(Thickness)mm*10 Layer or 100mm*12mm*12 |
King pin | JOST brand 2.0 or 3.5inch bolts type or Welding type |
Support leg | JOST brand D200T or China brand 28Tons (Double speed) |
Main beam | Height: 500mm, upper plate is 14mm, middle plate is 8mm, |
Brake chamber | WABCO RE 6 relay valve; T30/30+T30 Spring brake chamber(TKL brand); Two pieces of 45L air tanks |
ABS | Optional |
Twist locks | Four ,Eight or Twelve pieces (Lifting type or Twist Screw Type) |
Valve | WABCO valve |
Light | LED light |
Voltage | 24V |
Receptacle | 7 ways (7 wire harness) |
Tool box | One piece, 1m×0.5m×0.5m (Size can be choose freely)(equipped with 1 unit Tire spanner,1 unit gudgeon sleeve and 1 unit cranking bar) |
Painting | Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint |
Shipping terms | By bulk cargo carrier, RORO or 40HQ container. |
