Brand | Qi Lin |
Model | QLG9403GHYK |
Usage | Load chemical liquids |
Total weight | 40000kg |
Tare weight | 11000kg |
Max payload | 29000kg |
Tank volume | 47cbm |
Overall dimension | 12450mm*2500mm*3990mm |
Tank dimension | 11780mm*2180mm*2040mm |
Side protective device | Q235 steel,screw bolt connection |
Rear protective device | Q235 steel,welding connection |
Bottom edge height | 500mm |
Axle | 24000kg payload/3pcs |
Tire | 11.00R20 12PR,12R22.5 12PR /12pcs |
Leaf spring number | -/13/13/13 |
Wheelbase | 6350mm+1305mm+1305mm |
Rear tread | 1840mm/1840mm/1840mm |
Rear suspension | 1990mm |
Departure angle | 14° |
Braking system | With ABS system(4S/2M) |
Electrical system | 24 voltage,7 wire harness. |
Light | LED type |
Painting | With shot blasting and 4 layers painting,color is optional. |
Remark | The above mentioned data is for your reference only. The detailed specification will be subject to our final confirmation. |
