Model

QLG9400CCY

Function

Load container or bulk cargo

Tare weight

7000kg

Max payload

60000kg

Overall dimension

13000mm*2500mm*3750mm

Wagon box dimension

12850mm*2400mm*600mm

Protective device

Q235 steel,welding connection

Bottom edge height

500mm

Axle

24000kg payload/3pcs

Tire

12R22.5 12PR/12pcs

Wheelbase

6940mm+1310mm+1310mm

Rear tread

1840mm/1840mm/1840mm

Rear suspension

2200mm

Departure angle

14°

Braking system

With ABS system(CM2XL-4S/2M)

Electrical system

24 voltage,7 wire harness.

Light

LED type

Painting

With shoot blasting,and 4 layers painting,color is optional.

Remark

The above mentioned data is for your reference only.

The detailed specification will be subject to our final confirmation.
