Product Description
Stainless Steel material has good conductivity, corrosion resistance, good heat dissipation and easy processing characteristics, which are widely used in vehicles. It's another important feature is a relatively high mechanical properties, can meet the requirements of the automotive container materials, in line with the development trend of the requirements is an important way of lightweight technology.
| 34cbm 3 axle Stainless Steel Milk Tanker Trailer | |||||||||
| Trailer Model | QLG9403GNY | ||||||||
| Function | Load Milk | ||||||||
| Overall dimension | 11250*2500*3850mm | ||||||||
| Tank Body | 10850*2490*2000mm | ||||||||
| Max payload | 34cbm (34 Ton) | ||||||||
| Curb weight | 9.5 Ton | ||||||||
| Tank | 304stainless steel ,6mm Tanker body/shell end/ washboard | ||||||||
| Main Beam | down plate is 12mm,middle plate is 6 mm, | ||||||||
| Compartment | silo | ||||||||
| Bottom valve | aluminuim alloy 1 pcs | ||||||||
| Running constructon | |||||||||
| Axle | Fuwa 13T | ||||||||
| Axle Number | 3 pieces | ||||||||
| tyre | 11.00R20 | ||||||||
| Number of Tyre | 13 pieces ( 1 spare tire included) | ||||||||
| rim | 8.0-22.5/13 | ||||||||
| Twist lock | 12 pieces | ||||||||
| leaf-spring | 90width*10pieces*13mm/6 sets | ||||||||
| Kingpin | interchangeable 90# /50# | ||||||||
| Landing gear | 28T Made in China | ||||||||
| suspension | Mechanical suspension | ||||||||
| Tool box | 1 pcs standard | ||||||||
| Braking system | with ABS system made in China | ||||||||
| Electrical system | 24 voltage | ||||||||
| 7 ways(7 wire harness) | |||||||||
| Light | LED type | ||||||||
| Packing | Nude,Polish with Wax before Shipment | ||||||||
| Painting | Color is optional | ||||||||
| Remark | The above mentioned data is for your reference only. The detailed specification will be subject to our final confirmation. | ||||||||
Packaging & Shipping
1 Nude , Polish with water wax before shipment .
2 40HQ ,Ro-Ro ship and Bulk Ship Transport .
Our Services
Our engineer will go to your side when the oil tanker goes something wrong;
Any parts of the oil tanker will be send to you as soon as possible;
Technology consulting are appreciated all the time!
Company Information
1 Hebei Huaqi was established in 1956 . more than 60 years trailer making experiences .
2 We have more than 300 emplyee . with 24 technical engineers , 18 senior engineers .
3 we are one of the largest manufacturer in China , have passed ISO9001:2008 , CCC National Compulsory Certificate.
4 "Qi Lin" Brand is Famous brand in Hebei Province ,China .
Welcome you visit our factory !
1. We can pick up you in the airport port
2 book the hotel for you,
3. show around the workshop and production line
4. we can supply the truck parts
5. we can supply the stock trucks if you need the trucks urgently.
HONOR
PRODUCTION LINE
FAQ
1. Can i have samples of this type of trailer to test the quality?
Yes, you can buy any samples to test the quality,our MOQ is 1 set.
2. What's the delivery time and can you lower the price?
It depends on your order. The delivery time is within 15 workdays after we received your prepayment. If you have place an order of large quantities, then ,of course, the price can be lowered.
3. Can you supply some quick-wear trailer parts?
Yes, we can supply the trailer parts as your request,such as traction, traction pin, balance beam and semi-trailer plate spring, hanging accessories, turntable, all kinds of trailer brake pads, brake pan, bearings, etc
4. What's the payment method?
TT 30% as Deposit, Balance Before shipment by TT or L/C at sight
5.Do you have any used trailer for sale?
We have many trailers in stock for choice, from 2010-2014 year, the price are favorable
We'll show you our stock trailer if you need.
6. How to guarantee customers get the goods smoothly after they pay?
Don’t worry, dear. we joined the trade assurance. you can place the order by trade assurance,and the deposit will given to alibabba.if we don’t delivery products, the deposit will return to you.
7. How can you ensure the quality of the products?
Don’t worry, dear. we joined the trade assurance. If the products have quality problem when you received the goods, alibaba can give you advance payments.
