Product Description
Factory sale 3 axles 30000 liters stainless steel water tank semi trailer
Name | Water tank semi trailer |
Model | QLG9400GGS |
Function | Transport clean water |
Gross weight | 38000kg |
Curb weight | 7800kg |
Overall dimension | 9800mmX2500mmX3850mm |
Tank dimension | 9400mmX2350mmX1750mm |
Tank volume | 30000 liters |
Tank material | 304 stainless steel |
Tank thickness | Tank body 4mm/washboard 3mm/end plate 4mm |
Compartment | Single |
Manhole cover | Diameter 500mm/2pcs |
Gooseneck girder,high tensile Q345B steel | |
Landing gear | Fuwa 28T,two-speed manual operation |
Suspension system | Air suspension |
Axle | Fuwa 13T/3pcs |
Tire | 12R22.5/13pcs |
Rim | 9.0R22.5/13pcs |
Spare tire carrier | 1pc |
Tool box | Aluminium alloy/1pc |
Valve box | Aluminum alloy/2pcs |
Fire extinguisher | 8kg/2pcs |
Braking valve | Variable pressure relay valve |
3 inches/2pcs | |
Discharge pipe | 6m,3 inches/1pc |
Braking system | RE6 relay valve,T30/30 spring brake chamber,40L air tanks,ABS system |
Electrical system | 24 voltage,7 wire harness,LED lights. |
Painting
| Complete chassis sand blasting to clean rust ,1coat of anti-corrosive prime,2coats of final paint. |
Packing | Nude,polish with wax before shipment. |
Remark | The above mentioned data is for your reference only. The detailed specification will be subject to our final confirmation. |
Packaging & Shipping
1 Nude,Polish with water wax before shipment .
2 40HQ,Ro-Ro ship and Bulk Ship Transport .
Our Services
Our engineer will go to your side when the tank trailer goes something wrong;
Any parts of the tank trailer will be send to you as soon as possible;
Technology consulting are appreciated all the time!
Company Information
1.Hebei Huaqi was established in 1956 . more than 60 years trailer making experiences .
2.We have more than 300 emplyee . with 24 technical engineers , 18 senior engineers .
3.We are one of the largest manufacturer in China , have passed ISO9001:2008,CCC,SGS,UL Certificates.
4. "Qi Lin" Brand is Famous brand in Hebei Province,China .
Welcome you to visit our factory !
1.We can pick up you in the airport port ,
2 book the hotel for you,
3. show around the workshop and production line.
4. We can supply the truck parts.
5. We can supply the stock trucks if you need the trucks urgently.
Factory View
Production line
Other Products
Honor
FAQ
1. Can I have samples of this type of trailer to test the quality?
Yes, you can buy any samples to test the quality,our MOQ is 1 set.
2. What's the delivery time and can you lower the price?
It depends on your order. The delivery time is within 15 workdays after we received your prepayment. If you have place an order of large quantities, then ,of course, the price can be lowered.
3. Can you supply some quick-wear trailer parts?
Yes, we can supply the trailer parts as your request,such as traction, traction pin, balance beam and semi-trailer plate spring, hanging accessories, turntable, all kinds of trailer brake pads, brake pan, bearings, etc
4. What's the payment method?
TT 30% as Deposit, Balance Before shipment by TT or L/C at sight.
5.Do you have any used trailer for sale?
We have many trailers in stock for choice, from 2012-2016 year, the price are favorable.
We'll show you our stock trailer if you need.
6. How to guarantee customers get the goods smoothly after they pay?
Don’t worry, dear. we joined the trade assurance. you can place the order by trade assurance,and the deposit will given to alibabba.if we don’t delivery products, the deposit will return to you.
7. How can you ensure the quality of the products?
Don’t worry, dear. we joined the trade assurance. If the products have quality problem when you received the goods, alibaba can give you advance payments.
