Model number

QLG9403CCY

Function

Load container or bulk cargo

Gross weight

40tons

Curb weight

7tons

Max payload

33tons

Overall dimension

13000mm*2500mm*3800mm

Wagon box dimension

12850mm*2400mm*600mm

Tank material

Q235 steel plate

Side protection connection type

Welding

Rear protection connection type

Welding

Rear protective section dimension

120mm*60mm

Lower edge height to ground

520mm

Axle load

24tons

Number of axles

3 pieces

Wheelbase

6590mm+1305mm+1305mm

Rear tread

1840mm/1840mm/1840mm

Tire specification

12R22.5 12PR

Number of tires

12 pieces

Rim specification

9.0-22.5/12

Departure angle

15°

Rear suspension

2400mm

Braking system

With ABS system(CM2XL-4S/2M)

Electrical system

24 voltage,7 ways(7 wire harness)

Light

LED type

Painting

Color is optional.

Remark

The above mentioned data is for your reference only.

The detailed specification will be subject to our final confirmation.
