Model

QLG9403GNR

Function

Load bulk cargo

Overall dimension

10000mm*2500mm*3900mm

Max payload

60000kg

Main beam

Main beam height is 500mm,

upper/down plate is 14mm/16mm,middle plate is 6mm.

Side beam

200mm bending plate/180mm channel steel

Plate thickness

Bottom 5mm,side 4mm

Axle

Fuwa 13T/3pcs

Tire

11.00R20/12pcs

Rim

8.0-22.5/12

Leaf spring

90width*10pcs*13mm/6 sets

Kingpin

Interchangeable 90#/50#

Lifting

HYVA Brand,196mm*7350mm

Landing gear

28T made in China

Suspension

Mechanical suspension

Tool box

1pc standard

Braking system

with ABS system made in China

Electrical system

24 voltage,7 wire harness.

Light

LED type

Painting

With shot blasting and 4 layers painting,color is optional.

Remark

The above mentioned data is for your reference only.

The detailed specification will be subject to our final confirmation.
