PRODUCTS
Product Description
Characteristics
· Round design for easy loading and unloading.
· Transport sand, gravel and construction materials.
· Completely smooth in its interior without polishing and without grinding.
· High strength steel or Hardox Steel.
· With lower center of gravity.
· Capacities from 20 to 30 M³.
SPECIFICATIONS | |
BODY OF TRAILER | Carbon steel 3/16 and 1/4 |
FRAMEWORK | Carbon steel |
CHASSIS | Integral to the center of fifth wheel. |
Front and suspension | Made of Carbon Steel |
KING PIN | Carbon steel, interchangeable 2"/3.5" |
TIRE HOLDER | In Carbon Steel, basket type behind the landing gear. |
LODERA | Made of rigid plastic back and front with supports |
SUSPENSION | Mechanical |
AXELS | 3 axles lubricated with oil. BPW or FUWA brand |
BREAKS | Self-adjusting racks without dust cover, ABS brake system. |
RINES | In Steel, pre-painted white |
TIRES | Optional |
HYDRAULIC SYSTEM | Cylinder of FUWA |
PNEUMATIC SYSTEM | Pneumatic system for rear door opening. |
STAIRS | Carbon steel, located one on each side of the van. |
LANDING GEAR | 1 set , 2 speeds. |
MUDGUARD | Aluminum / plastic on suspension |
WIRING | Exposed Harness |
LIGHTS | Type LEDS with reflectors and directional lights |
PAINTING | Epoxy |
DRIVING HOOK | Optional |
OPTIONAL EQUIPMENT | KIT HYDRAULIC: PTO installation, pneumatic drive, direct coupled, hydraulic pump direct coupling, tank for hydraulic oil type backpack, console to operate PTO pump. |
