| Overall dimension | 8500*2480*1520mm |
| Axle number | 3 |
| tyre | 12R22.5 |
| Axle load | 13Ton |
| suspension | Four leaf springs |
Wheel | 12 |
curb weight | 5.1ton |
payload | 40ton |
Longitudinal beam height | 480mm |
On the wing | 14mm |
The wing | 16mm |
plate | 6mm |
| landing leg | 28T external linkage branch fade |
| Electrical system | 24 volt electrical system. LED lights, 7 pin electrical connector. Parking .stop,reverse,number plate and indicator lights. rear lights conform to European standard, rear front and side reflectors |
| Color | Optional |
| Braking system | without ABS system made in China |
| Packing | Nude,Polish with Wax before Shipment |
| Remark | The above mentioned data is for your reference only. The detailed specification will be subject to our final confirmation. |
