Model

QLG5140TSMGYY

Overall dimension

7690mmX2500mmX3450mm

Curb weight

9750kg

Max payload

4120kg

Tank volume

5200 liters

Drive form

4X4

Steering form

Power steering

Transmission

Manual

Cab

2 passengers

Axle load

7000kg/7000kg

Tire

14.00R20 20PR/4pcs

Front/rear tread

2100mm/2100mm

Front/rear suspension

1830mm/1760mm

Wheelbase

4100mm

Approach/departure angle

30°/17°

Leaf spring number

11/11+6

Engine type

6 cylinders,in-line,water cooling,4 stroke

Engine power

232kw

Displacement

8900ml

Braking system

With ABS system

Max speed

75km/h

Fuel type

Diesel

Painting

Color is optional

Remark

The above mentioned data is for your reference only.

The detailed specification will be subject to our final confirmation.
