Brand

Qi Lin

Model

QLG5253GYY

Usage

Load gasoline/diesel/petroleum

Overall dimension

10160mmX2500mmX3170mm

Total weight

25000kg

Tare weight

10230kg

Max payload

14575kg

Tank parameters

Tank volume

20000 liters

Tank material

Carbon steel

Tank dimension

7450mmX2370mmX1670mm

Tank thickness

4mm/4mm/4mm

Compartments

single

Manhole

2pcs

Chassis parameters

Chassis brand

Foton/Dongfeng/JAC/FAW etc.(optional)

Drive type

Left/Right hand drive(optional)

Drive form

6X2

Axle

3pcs

Tire

10.00R20 18PR/8pcs

Leaf spring number

10/10/10+9,10/10/9+6

Wheelbase

1860mm+4800mm

Front/rear tread

1890mm/1847mm

Front/rear suspension

1365mm/2135mm

Approach/departure angle

18°/11°

Fuel type

Diesel

Cab

3 passengers

Engine

Commins/Yuchai/Chaochai/Weichai etc.(optional)

Emission

Euro 2/3/4/5(optional)

Horse power

207hp

Displacement

6700ml

Max speed

80km/h

Braking system

With WABCO ABS system

Electrical system

24 voltage,7 wire harness,LED lights.

Painting

With shot blasting and 4 layers painting,color is optional.

Remark

The above mentioned data is for your reference only.

The detailed specification will be subject to our final confirmation.
