Model number

QLG5253GYY

Function

Load gasoline

Total weight

25000kg

Curb weight

10230kg

Max payload

14575kg

Tank volume

21.8cbm

Overall dimension

10160mm*2500mm*3170mm

Tank dimension

7450mm*2370mm*1670mm

Protective section material

Q235-A steel

Protective section connect type

Screw bolt

Passengers allowed

3 persons

Rear protective section dimension

100mm*50mm

Height of lower edge to ground

420mm

Axle load

6750/6750/11500

Number of axles

3 pieces

Wheelbase

1860mm/4800mm

Front/rear tread

1890mm/1847mm

Tire specification

11.00R20

Number of tires

8 pieces

Front/rear suspension

1365mm/2135mm

Approach/departure angle

18°/11°

Fuel type

Diesel oil

Max speed

80km/h

Braking system

With WABCO ABS system

Electrical system

24 voltage,7 ways(7 wire harness)

Light

LED type

Painting

Color is optional.

Remark

The above mentioned data is for your reference only.

The detailed specification will be subject to our final confirmation.
