Tare weight

9805kg

drive type

6*4

Overall dimension

10055*2500*3400mm

Protective device

Q235-A steel,screw bolt connection

Tire

12R22.5

Front/rear tread

2035mm,1850/1850mm

Wheelbase

5775+1400mm

Braking system

With ABS system

Emission

Euro 5

Fuel type

Diesel

Max speed

80km/h

Cab passenger number

3 persons

Electrical system

24 voltage,7 wire harness.

Light

LED type

Painting

With shot blasting and 4 layers painting,color is optional.

Remark

The above mentioned data is for your reference only.

The detailed specification will be subject to our final confirmation.
