Brand | QI LIN |
Name | Low bed truck |
Model | QLG5043TDP |
Overall dimension | 5995x2500x2420mm |
Max Payload | 2795kg |
Curb weight | 4490kg |
Chassis brand | HFC1043P91K2C2V |
Drive type | Left/Right hand drive(optional) |
Drive wheel | 4X2 |
Transmission | LCT450B(aluminum) |
Tire | 7.50-16LT 6PR |
Rear axle | Ratio of 4.875 |
Front/rear tread | 1685mm/1525mm |
Front/rear suspension | 1100mm/1587mm |
Wheelbase | 3308mm |
Leaf spring number | 13/8+6 |
Engine | Yunnei D30TCIE1 |
Emission | Euro 2/3/4/5(optional) |
Displacement | 2977ml |
Horse power | 156hp |
Maximum output | 115kw |
Fuel type | Diesel |
Electrical system | 24 voltage,7 wire harness,LED lights. |
Painting | With shot blasting and 4 layers painting,color is optional. |
Remark | |
1.The above mentioned data is for your reference only. | |
2.The detailed specification will be subject to our final confirmation. |
