PRODUCTS
Brand | QI LIN |
Name | Van cargo truck |
Model | QLG5046XXY-F1 |
Overall dimension | 5515mmX1960mmX2880mm |
Van dimension | 3670*1900*1810mm |
total weight | 4395kg |
Curb weight | 2270kg |
Max payload | 1995kg |
Drive type | Left/Right hand drive(optional) |
Drive wheel | 4X2 |
Transmission | Manual,5 forward gears,1 backward gear. |
Cab | 3 passengers |
Tire | 6.50R16LT |
Front/rear tread | 1415mm;1435mm |
Front/rear suspension | 1100/1565mm |
Wheelbase | 2850mm |
Approach/departure angle | 23°/18° |
Leaf spring number | 7/7+5 |
Engine | 4A2-88C50 |
Emission | Euro 5 |
Displacement | 2270ml |
Horse power | 88hp |
Max speed | 105km/h |
Fuel type | Diesel |
Electrical system | 24 voltage,7 wire harness,LED lights. |
Painting | With shot blasting and 4 layers painting,color is optional. |
Remark | |
1.The above mentioned data is for your reference only. | |
2.The detailed specification will be subject to our final confirmation. |
