Brand | QI LIN |
Name | van truck |
Model | EQ5041CCY8BD2AC |
Overall dimension | 5995MM*2470MM*3250MM |
Van dimension | 4170MM*2300MM*2030(high top ) |
Gross weight | 4500kg |
Curb weight | 2700kg |
Max payload | 2000kg |
Chassis specifications | |
Chassis brand | Jiefang/Dongfeng/Foton/JAC(optional) |
Drive type | Left/Right hand drive(optional) |
Drive wheel | 4X2 |
Transmission | Manual,6 forward gears,1 backward gear. |
Cab | 3 passengers |
Tire | 8.25-16LT 6PR/6pcs |
Front/rear axle | 1795kg/2700kg |
Front/rear tread | 1769mm/1629mm |
Front/rear suspension | 1130mm/1557mm |
Wheelbase | 3308mm |
Approach/departure angle | 20°/14° |
Leaf spring number | 8/10+7 |
Engine | Commins/Yuchai/Chaochai(optional) |
Emission | Euro 2/3/4/5(optional) |
Displacement | 3760ml |
Horse power | 129hp |
Braking system | With ABS system |
Max speed | 103km/h |
Fuel type | Diesel |
Electrical system | 24 voltage,7 wire harness,LED lights. |
Painting | With shot blasting and 4 layers painting,color is optional. |
Remark | |
1.The above mentioned data is for your reference only. | |
2.The detailed specification will be subject to our final confirmation. | |
