| brand | QI LIN |
| name | low bed truck |
| model | QLG5311TDP |
| overall dimension | 11100*2495*3450 |
| payload platform length | 7200 |
| rear ramp length | 1000 |
| gross weight | 30950 |
| curb weight | 16000 |
| max payload | 14755 |
| chassis brand | dongfeng/foton/jac/hini(optional) |
| drive type | left/right hand drive(optional) |
| drive wheel | 8*4 |
| transmission | manual, 9 forward gears, 1 bakcward gear |
| cab | 3 passengers |
| tire | 10.00R20 18PR/12pcs |
| axle payload | 6500/6500/17950 |
| axle number | 4pcs |
| front/rear tread | 2040/1860 |
| front/rear suspension | 1495/2655 |
| wheelbase | 1800+3800+1350 |
| approach/departure angle | 27/12 |
| leaf spring number | 9/9/12 |
| engine | commins/yuchai/chaochai/hino(optional) |
| emission | euro2-euro5 |
| displacement | 9726 |
| horse power | 300 |
| braking system | with ABS system |
| max speed | 80 |
| fuel type | diesel |
| electrical system | 24 voltage. 7 wire harness, LED lights |
| painting | with shot blasting and 4 layers painting, color is optional. |
Remark
1.The above mentioned data is for your reference only.
2.The detailed specification will be subject to our final confirmation.
