Overall dimension

5250MM*1900MM*2270MM

Van dimension

3500MM*1800MM*400MM

Gross weight

3775kg

Curb weight

2150kg

Max payload

1500kg

Chassis brand

DONGFENG

Drive type

Left/right hand drive (optional)

Drive form

4X2

Transmission

Manual,5 forward gears,1 backward gear

Cab

Single row cab ,2 passengers

Tire

6.50R16 /6pcs

Front/rear tread

1450mm/1470mm

Front/rear suspension

1230mm/1420mm

Wheelbase

2600mm

Approach/departure angle

21°/15°

Engine model

QUANCHAI 4A2-88C33

Engine type

4 cylinders,in-line,electronic control,water cooled

Displacement

2270ml

Rated power

65kw

Horse power

88hp

Max speed

103km/h

Fuel type

Diesel

Braking system

Air brake,ABS optional

Electrical system

24 voltage,7 wire harness,LED lights

Remark

The above mentioned data is for your reference only.

The detailed specification will be subject to our final confirmation.
