Function | Load light cargo |
Total weight | 4490kg |
Tare weight | 3660kg |
Max payload | 700kg |
Overall dimension | 5995mm*2080mm*2980mm |
Down edge height | 460mm |
Axle | 1620kg/2870kg payload/2pcs |
Tire | 7.00R16LT 8PR/6pcs |
Front/rear tread | 1440mm/1395mm |
Front/rear suspension | 1090mm/1597mm |
Wheelbase | 3308mm |
Approach/departure angle | 23°/15° |
Braking system | with ABS system(CM4XL-4S/4K(4S/4M)) |
Max speed | 85km/h |
Passenger limit | 2 persons |
Fuel type | Diesel |
Electrical system | 24 voltage,7 wire harness. |
Light | LED type |
Painting | With shot blasting and 4 layers painting,color is optional. |
Remark | The above mentioned data is for your reference only. The detailed specification will be subject to our final confirmation. |
