overall dimension | 9995*2550*3960 |
van dimension | 7650*2450*2600 |
gross weight | 15800 |
curb weight | 8100 |
max payload | 1505 |
chassis brand | DONGFENG/FOTON/JAC(optional) |
drive type | left/right hand drive(optional) |
drive wheel | 4*2 |
transmission | manual, 8 forward gears, 2 backward gears |
cab | 3 passengers |
tire | 9.00R20/6pcs |
axle number | 2pcs |
front/rear axle payload | 5800/10000 |
front/rear tread | 1900/1820 |
front/rear suspension | 1430/2965 |
wheelbase | 5600 |
approach/departure angle | 20/8 |
leaf spring number | 7/9+6,8/10+8 |
engine | commins/yuchai/chaochai(optional) |
emission | euro 2/3/4/5(optional) |
displacement | 5900 |
horse power | 180 |
braking system | with ABS system |
max speed | 90 |
fuel type | diesel |
fuel tank | aluminum alloy material , 200L |
electrical system | 24 voltage,7 wire harness, LED lights. |
painting | with shot blasting and 4 layers painting , color is optional. |
Remark
1.The above mentioned data is for your reference only.
2.The detailed specitication willbe subject to our final confirmation.
