PRODUCTS
tonnage level | light duty |
overall dimension | 5995*2200*2900 |
van dimension | 4165*2050*2100 |
gross weight | 4330 |
curb weight | 2705 |
max payload | 1495 |
max speed | 95 |
painting | with shot blasting and 4 layers painting, color is optional. |
chassis brand | Foton |
drive type | left hand drive |
drive form | 4*2 |
cab | 1995mm width, 3 passengers, air conditioner optional. |
transmission | manual, 5 forward gears, 1 backward gear. |
wheelbase | 3360 |
front/rear suspension | 1120/1515 |
front/rear tread | 1530/1485 |
front/rear axle payload | 1320/3010 |
rear axle speed ratio | 6.142 |
tire | 7.00R16/6pcs |
leaf spring number | 3+1/6+7 |
approach/departure angle | 21/17 |
braking system | with ABS system |
electrical system | 24 voltage, 7 wire harness, LED lights. |
engine brand | Foton |
engine type | 4 cylinders, vertical, inline, water cooled. |
displacement | 2771 |
horsepower | 108 |
torque | 280N.m |
maximum torque speed | 1700-2300RPM |
rated rotor speed | 3600RPM |
fuel type | Diesel |
fuel tank | plastic material, 80L |
Remark
1.The above mentioned data is for your reference only.
2.Our company will manufacture the produce according to your requirements.
3.The detailed specifications will be subject to our final confirmation.
