Function

Load cargo

Total weight

4490kg

Curb weight

3660kg

Max payload

700kg

Overall dimension

5995mm*2080mm*2980mm

Down edge height

460mm

Axle number

2 pcs

Axle load

1620kg/2870kg

Tire number

6 pcs

Front/rear tread

1440mm/1395mm

Front/rear suspension

1090mm/1597mm

Wheelbase

3308mm

Approach/departure angle

23°/15°

Braking system

with ABS system

Max speed

85km/h

Passenger limit

2 persons

Fuel type

Diesel

Electrical system

24 voltage,7 wire harness.

Light

LED type

Painting

With shot blasting and 4 layers painting,color is optional.

Remark

The above mentioned data is for your reference only.
The detailed specification will be subject to our final confirmation.
