Model

QLG9401GFW

Usage

Load fuel /diesel

Total weight

40000kg

Tare weight

9500kg

Max payload

30500kg

Tank volume

36cbm

Tank material

STAINLESS steel

Overall dimension

11100x2500x3990mm

Tank dimension

10600mm*2100mm*2300mm

Side protective device

Q235 steel,screw bolt connection

Rear protective device

Q235 steel,welding connection

Bottom edge height

520mm

Axle

24000kg payload/3pcs

Tire

11.00R20 12PR,12R22.5 12PR

Leaf spring number

-/10/10/10,-/9/9/9,-/13/13/13

Wheelbase

5530+1310+1310mm

Rear tread

1840mm/1840mm/1840mm

Rear suspension

1450mm

Departure angle

22°
