Overall dimension | 6995MM*2230MM*2490MM | ||
Van dimension | 5150MM*2120MM*220MM | ||
Gross weight | 8275KG | ||
Curb weight | 3800KG | ||
Max payload | 5000KG | ||
Chassis brand | FOTON /DONGFENG optional | ||
Drive type | Left/right hand drive (optional) | ||
Drive form | 4X2 | ||
Transmission | Manual,6forward gears,1 backward gear | ||
Cab | Single row cab ;3 passengers ;with air-condition | ||
Tire | 7.50R16 /6pcs | ||
Rear axle speed ratio | 4.875 | ||
Air cylinder | 4 | ||
Wheelbase | 3800mm | ||
Fuel type | diesel | ||
Engine model | YC4FA130-50 | ||
Engine type | Vertial type;in-line engine;water -cooling;four-stroke | ||
Displacement | 2982ML | ||
Rated power | 95KW/H | ||
Horse power | 130HP | ||
Torque | 340N.M | ||
Max torque rotate speed | 1600-2400RPM | ||
Braking system | Air brake,ABS optional | ||
Electrical system | 24 voltage,7 wire harness,LED lights | ||
Remark | The above mentioned data is for your reference only. The detailed specification will be subject to our final confirmation. | ||
