| brand | QI LIN |
| model | QLG5046XZH |
| overall dimension | 5995*1990*2200 |
| gross weight | 8500 |
| curb weight | 3365 |
| max payload | 5000 |
| van specifications | |
| front portal | huaqi reinforced 1 standard |
| side door | 1.5mm thickness, 400mm height |
| material | Q235 carbon steel |
| painting | with shot blasting and 4 layers painting, color is optional. |
| chassis specifications | |
| chassis model | Dongfeng EQ1060TJ20D3 |
| drive type | left/right hand drive(optional) |
| drive wheel | 4*2 |
| transmission | manual, 5 speed forward with 1 reverse |
| cab | 3 passengers |
| axle | 2pcs |
| tire | 8.25R16LT/7pcs(include 1 spare tire, brand is optional) |
| front/rear tread | 1506/1466 |
| front/rear suspension | 1032/1488 |
| wheelbase | 3300 |
| approach/departure angle | 19/15 |
| leaf spring number | 8/9+5, 6/8+4 |
| engine | CY4100-E3F(optional) |
| emission | euro 3 |
| horse power | 100hp |
| braking system | with ABS system |
| max speed | 80 |
| fuel type | diesel |
| electrical system | 24 voltage, 7 wire harness |
| light | LED type |
| remark | The above mentioned data is for your reference only The detailed specification will be subject to our final confirmation |
